Signal Processing Group Inc., provides extremely cost effective services

Signal Processing Group Inc., delivers rf design, rfic, rf ic, rf circuit design, ic design, analog design, rf technology, analog circuit design, asic chip, integrated circuit design, rf devices, rf engineers,

Signal Processing Group Inc, has been operating in Arizona fo the past 26 years as a service company providing design, development and manufacturing services to companies in the valley. We are wholly American owned and operated. We offer the services listed below at extremely cost effective rates. Please try us and see. Your success is our success. No project is too small for us.

Here are the services that we provide:

  1. Product definitions and specification building
  2. Feasibility studies
  3. Prototype design, hardware and software
  4. Computer aided design
  5. Applications software design ( APPS)
  6. Printed circuit board design, fabrication, assembly and test
  7. Semiconductor ASIC design, development, fabrication, assembly and test. Commercial , Industrial and Military standards.
  8. Multi-chip modules.
Check out the blog.
More details on services.
More details on technology we use.
Check out our FAQs.

Your direct contact is: Ain Rehman. Cell Phone: 602-626-0272, email:

Ain Rehman is your local contact

Signal Processing Group Inc, 51W. Elliot Road, #103, Tempe, Arizona 85284



SPG designs, develops and delivers custom analog and RF/wireless asics and modules.

FPGA Design and development service

Contact SPG using phone: 602-626-0272 for fast service.

A wideand RF detector ( 40 Mhz to 3 Ghz) -75 dBm to 5 dBm input

A wideband RF detector

A wideband RF detector

Linear detector performance

Linear detector performance curves

A wideband linear RF detector

Price for one unit: $25.00. Lead time for delivery 3 days. 30 Day return policy. Pricing for 100 units or more: $20.00 per unit.  Please contact Signal Processing Group Inc. for details for purchase from Signal Processing Group Inc. Email: 24/7

Wideband RF detector perforamce , more details

Contact Signal Processing Group Inc.

Please contact Signal Processing Group Inc. on email: . We will answer within 24 hours.

2 stage 35 dB gain RF amplifier. Front of the module

Full range frequency response

2 stage amplifier deta

Please see details at    Delivery lead time is 3 days. Return within 30 days for a full refund. Price is $15.00 for one unit and $10.00 per unit in volumes of 100. For higher volumes than 100 please contact Signal Processing group Inc.

miniature LNA module

Mni LNA performance

Delivery lead time is 3 days. Return within 30 days for a full refund. Price is $15.00 for one unit and $12.00 per unit in volumes of 100. For higher volumes than 100 please contact Signal Processing Group Inc. at email: or call 602-626-0272 for fastest service.

A high frequency divider from 500 Mhz to % Ghz+

The input interface.
The frequency divider has a differential analog interface. The following parameters apply:
The minimum frequency that can be input is 500 Mhz and the maximum frequency is 6.0 Ghz.
The RF input level is 5 dBm to – 5 dBm. For lower frequencies make sure that the slew rate is
greater than 560 V/us. The input is biased by two 500 Ohm resistors connected to a 1.6V DC bias.
Therefore AC coupling is used at the input. These are two 100pF capacitors.
The output interface.
The output is single ended. The output driver is capable of sourcing and sinking 24 mA. The
equivalent output impedance is 50 Ohm. To avoid reflections it is recommended that the divider
work into a 50 Ohm load.
General operation.
The inputs are applied to the input SMA I/O. The product will work with both a differential input as
well as a single ended input. However, a differential input works best. The division ratio is applied
to the N1 and N2 control inputs as follows:
N2 N1 Division ratio
0 0 8
0 1 16
1 0 32
1 1 64
The logic levels are:
Logic level Voltage
1 1.4V minimum
0 0.6V maximum
The supply voltage interface.
The operating supply voltage is 3.3V typical. The quiescent (DC) operating supply current is 2 mA.

A high frequency divider 500 Mhz to 5 Ghz+

Contact Signal Processing Group Inc for details and acquisition

Please contact Signal Processing Group Inc. at email: or telephone 602-626-0272. Get a response within minutes or worst case 24 hours if contact is by email.

SPDT DC to 3 Ghz RF switch

DC to 3 Ghz RF SPDT switch

RF Switch typical features

Supply voltage = Vcc = 0/+5 Vdc
Operatng temperature = TA = -50° C to 125 Deg C
Operating impedance = 50 Ohm
Input power for 1 dB
compression ( 5.0V system) = 37 dBm ( f = 0.5 to 3 Ghz)
Input third order Intercept = 64 dBm ( 0 to 5.0V system, f = 0.5 to 3 Ghz)
Operating frequency range = DC to 3 Ghz.
Insertion loss DC to 3 Ghz = 0.8 dB
Isolation DC to 3 Ghz = 14 dB minimum
Return loss DC to 3 Ghz = 20 dB
50% contl to 10/90 %
( ON/OFF) = 120 ns

A single stage RF amplifier as a gain block

A single stage RF amplifier summary specifications

Summary Specifications

Gain,  Operating: 19.5 dB
Operating frequency range: 1.0 – 2700 Mhz
OIP3: (Pout = 19.0 dBm),  -8.5 dBm
P1dB: 4.6 dBm
N.F: 4.2 dB
Supply voltage Operating: 3.3  – 5.5 Volts

Price: single unit $7.50, 100 units : $5:50.

Free delivery, shipping lead time 2 days.

30 day return policy, buyer ships.
Supply current Supply = 5.0V,  23.0 mA

Embedded design and development

Signal Processing Group Inc. is offering embedded design and development using Microchip processors. Please contact us on for more information
